415 W RMS, max SPL of 128 dB at 1 m
Class D amplifier
Compact and lightweight
Easy daisy chain with XLR and powerCON
Stage proof design with rugged metal protective grill
The DAP M15 is an active floor monitor speaker with a 15-inch woofer and a total power of 415 watt, especially built to amplify sounds on stage. It features a 60° wedge design and a coaxial speaker for transparent and direct 'in your face' sound with consistent coverage. The powerful Class D amplifier provides good sound quality, even at a high volume.
The built-in amplifier of the M15 has an XLR/Jack input connector, XLR line output connector and powerCON in and through connector. It's equipped with a volume control, EQ preset selector, ground switch and AC fuse for adjusting the sound and output level.
Integrated handles protect the recessed amplifier and connectors from getting damaged and makes it a very easy-to-handle floor monitor, even in the toughest stage environments.
Output Power: Class D, 350W LF power, 65W HF power
Maximum SPL @1M: 125dB/ 128dB Peak
Frequency resp. (-10dB): 60Hz – 20kHz
Transducer Low: 15" Woofer, 2,56" Vioce Coil
Transducer High: 1" Neodymium Compression Driver,
1" Voice Coil
Nom Dispersion (HxV): 70° x 70° (-6dB)
Audio Input: XLR/ Jack Combo balanced
Link Output: XLR-male balanced
External Controls: Mic/Line switch, EQ Preset switch (Monitor/FOH),
Ground Lift switch, Volume control,
Signal-Limiter indication LED,
Power Switch with green LED
Electronic Protection: Thermal/ Overload/ Limiter/ Compressor
Mounting: Floor and Integrated 35mm Pole Socket
Power Supply: AC 100V~240V, 50 Hz/60Hz (SPSU)
Power Input: Neutrik Powercon
Housing: Wedge design 15 mm MDF
with Scratch Resistant Black Paint
Dimensions (HxWxD): 493 x 460 x 399 mm
Net Weight: 18,4 kg
