250 W 100 V 4-Zone Mixer Amplifier with adjustable zone volume levels
4 stereo in, 3 mic in, FM/DAB+ tuner & USB player
Line-output per zone & special output for only music/mics
Chime & Ducking
Loop-through connection
19" 3U rack design
The DAP ZA-9250VDAB is a 250-watt 100 V 4-zone mixer amplifier and media player with zone volume control. The 3 microphone/line inputs are equipped with +48 V phantom power and you have a choice of 7 audio sources, including a built-in USB player with two USB inputs (front and rear) and FM/DAB+ tuner with which you can store up to 10 audio stations.
The ZA-9250VDAB has several functions. For example, it has a special input for emergency announcements (such as a fire alarm) that will override all other inputs. It is also equipped with an adjustable chime function, ducking level control, loop-through connection and a line output that can be used as a line output, for music only or microphones only. Besides, each zone also has its own line outputs for being able to connect extra amplifiers, allowing you to extend the PA system if needed.
This 100 V zone mixer amplifier is designed to support a PA system intended for intercommunication or background music in public and business areas such as convention halls, shopping malls, dining halls, auditoriums and recreational areas. It has an integrated protection circuit to protect against overload and short circuit of the output. This results in very high reliability and easy installations without the need for additional audio processors.
Outputs
Power Amplifier RMS Output 250 W
Output Channels 4
Output Mode Parallel
Output Connector Terminal
Main Outputs 2
Main Output Connector 3-pin XLR, RCA
Zone Outputs 4
Zone Output Connector Terminal, RCA
Headphone Output 1
Headphone Output Connector TS balanced 6.3 mm
Inputs
Mono Inputs 3
Mono Input Connector 3-pin XLR, Terminal, TS unbalanced 6.3 mm
Stereo Inputs 3
Stereo Input Connector RCA, TRS balanced 3.5 mm
Auxiliary Inputs 1
Auxiliary Input Connector RCA, TRS balanced 3.5 mm
Transformer 100 V
Playback
Supported Audio Files MP3, WAV
Supported Format FAT16, FAT32
Maximum Storage Size 32 GB
Media Input/Output USB-A
Playback Functions Up (Skip), Down (Skip), Play, Pause, Stop, Time, Folder
Audio Specifications
Phantom Power 18 V
Sound Editing
Parametric Channel Equalizer 2 Bands
Input Channel Equalizer Gain Range 12 dB
Input Channel Fixed Frequencies 100, 12.000 Hz
Microphone Input Equalizer Gain Range 12 dB
Parametric Microphone Equalizer 2 Bands
Microphone Input Fixed Frequencies 100, 12.000 Hz
Speech Filter Attenuation 3 dB
Speech Filter Frequency 300 Hz
Wireless Specifications
FM Frequency Start 87.5 MHz
FM Frequency End 108 MHz
FM Antenna Impedance 75 Ω
DAB+ Frequency Start 174 MHz
DAB+ Frequency End 230 MHz
Internal Storage
User Presets Capacity 10
Control and Programming
Display 14-segment
Electrical Specifications and Connections
Power Supply 115-230 V AC 50/60 Hz
Backup Power Supply 24 V DC
Power Consumption 514 W
Fuse 4 A
Power Connector In IEC
Data Connector In USB
Mechanical Specifications
Height (mm) 134 mm (5.276″)
Width (mm) 483 mm (19.016″)
Depth (mm) 328 mm (12.913″)
Installation Depth (Excl. Connector) 328 mm (12.913″)
Flightcase Size 19"
Rack Units 3 U
Housing Steel
Colour Black
Finish Powder Coating
Weight 14 kg (30.865 lb)
IP Rating IP20 (indoor use only)
Amplifier Cooling Axial fan
Product Properties
PTT Yes
Chime Yes
Ducking Yes
VOX Yes
Telephone Input Yes
Electronic Protection Overload, Short circuit
LED Indicators Channel select, Output level, Power
Included Items
Included Cables IEC cable
Included Accessories FM Antenna, Green terminal connector, Rubber feet
